NUX NDD-6 Duotime Dual Delay Engine

NUX
£85.00 GBP

Mint Condition and Boxed



Double the delay

Packed with functionality but with a focus on user-friendliness, use the detailed controls of the NUX NDD-6 Duotime Dual Delay Engine to carve out your dream delays with ease. With five independent delay modes, each capable of being minutely fine-tuned, the ability to customise your echoes to taste allows the Duotime to become a versatile powerhouse of delay:

  • Level - Alter the delay mix level. In Loop Mode, this becomes loop level.
  • Type - Select from 5 delay types:
    • Analog: Based on classic bucket brigade discrete-time analog delays. Warm and characterful tones.
    • Tape: Based on the iconic Space Echo , get authentic saturation and echo.
    • Digi: More modern-sounding with subtle compression and filtering to remove harsh digital qualities.
    • Mod.: Modulated to unlock a more wacky sound signature.
    • Verb: Added reverberation for instant depth. By feeding shimmer into a plate algorithm, you get distinctive reverb coupled with huge delays.
  • Parameter -
    • For Analog Delay, PARAMETER controls Modulation Depth. Increase to get wider modulated sound.
    • For Tape Echo, PARAMETER controls signal saturation. Increase to get more saturated and distorted sound.
    • For Digi Delay, PARAMETER controls signal hardness. Increase to get a more compressed and brighter sound.
    • For Mod Delay, PARAMETER controls Modulation Depth. Increase to get a wider modulated sound.
    • For Verb Delay, PARAMETER controls Reverb and Shimmer mix level. Increase to get more depth and a 3 dimensional feeling.
  • Time 1 - Adjust the length of Delay 1.
  • Repeat 1 - Alter how many repetitions Delay 1 generates.
  • Time 2 - Adjust the length of Delay 2.
  • Repeat 2 - Alter how many repetitions Delay 2 generates.
  • Tap Tempo - Manually set the speed and sub-divisions of the delay.

All housed in a robust enclosure that helps ensure reliable performance. This is a pedal you're not going to want to put down, and hours upon hours of experimentation requires a unit that can easily handle the rigours of extensive use without compromising on performance. Regardless of whether you're on stage, in the studio, or just dialing in luscious delays while practicing, this dual delay pedal will always deliver articulate repetitions with precision.

Specs

  • Sampling rate: 48kHz
  • A/D Converter: 32Bit
  • Signal Processing: 32Bit
  • 9 Frequency Response: 20Hz 20kHz - ±1dB
  • Maximum input level: 10dBu/2.8Vrms
  • Input Impedance: 5MΩ
  • System Latency: 1ms
  • Maximum output level: 10dBu/2.8Vrms
  • Output Impedance: 1kΩ
  • Dynamic Range: 102dBu
  • THD+N Rato: 0.02 /-70dB(A-Weighting)@input 1Vrms,1kHz
  • Power: 9VDC(Negative tip,Optional ACD-006A adapter)
  • Current Draw: less than 150mA
  • Dimensions: 105(L)X115(W)X58(H)mm
  • Weight: 440g
